COOH Functionalized Single Walled-Double Walled Carbon Nanotubes

$77.80 - $125.00 / per gram

Are COOH functionalized Single Walled-Double Walled Carbon Nanotubes right for you?  SW-DWNTs are well suited to electronic applications.  Try some today!

Product Price

Description

COOH Functionalized Single Walled-Double Walled Carbon Nanotubes

Our COOH Functionalized Single Walled-Double Walled Carbon Nanotubes are made by CCVD and purified and functionalized using concentrated acid chemistry. Carbon Nanotubes (CNTs) have proven to offer a unique properties of stiffness and strength largely due to their high aspect ratio and all carbon structure. The thermal and electrical conductivity found in CNTs is much higher than that of other conductive or fibrous additive materials. Surfactants are used to stabilize dispersions in DI Water or other aqueous solvent mixtures. The most common surfactants used are PVP, SDS, or SDBS. The carbon atoms in CNTs are arranged in a planar honeycomb lattice structure in which each atom is connected via a strong chemical bond to the three neighboring atoms. These strong bonds are the reason that the basal plane elastic modulus of graphite is one of the largest of any known material. Having such strong bonds at the atomic level as well as a high aspect ratio, Carbon Nanotubes are expected to be the ultimate high-strength fibers.

COOH Functionalized Single Walled-Double Walled Carbon Nanotubes Specifications

Outer Diameter: 1-4nm

Inside Diameter: 0.8-1.6nm

Length: 5-30um

Ash: <1.5 wt%

Purity: >90 wt%

Additional MWNT content: >5wt%

Amorphous Carbon Content: <3wt%

Length: 5-30um

Specific Surface Area: 407 m2/g

Electrical Conductivity: >100 S/cm

OH Functionalized SWNTs contain 3.9% OH groups

COOH Functionalized SWNTs contain 2.7% COOH groups

Bulk density: 0.14 g/cm3

True density: ~2.1 g/cm3
