NH2 Functionalized Single Wall-Double Walled Carbon Nanotubes

NH2 Functionalized Single Wall-Double Walled Carbon Nanotubes

$156.25 - $300.00 / per gram

This product is produced by CCVD and is further purified or functionalized using a Dielectric Barrier Discharge process which provides greater control over the desired type & amount of Amine functionality which produces an exfoliated product that is much easier to disperse in the host matrix.  Amine functionalized carbon nanotubes can provide for covalent bonding to the matrix.

Product Price

Product Description

NH2 Functionalized Single Wall-Double Walled Carbon Nanotubes

Our NH2 Functionalized Single Wall-Double Walled Carbon Nanotubes is produced by CCVD and is further purified or functionalized using a Dielectric Barrier Discharge process which provides greater control over the desired type & amount of functionality which produces an exfoliated product that is much easier to disperse in the host matrix. The amino termination allows further chemistry of the functionalized carbon nanotubes and makes possible covalent bonding to polymers and biological systems such as DNA and carbohydrates. Carbon Nanotubes have proven to offer a unique properties of stiffness and strength largely due to their high aspect ratio and all carbon structure. The thermal and electrical conductivity found in carbon nanotubes is very high compared to other conductive or fibrous additive materials.  Select a functionalized product when trying disperse carbon nanotubes into certain host matrices to assist in dispersion.

NH2 Functionalized Single Wall-Double Walled Carbon Nanotubes Specifications

Outer Diameter: 1-4nm

Inner Diameter: 0.8-1.6nm

Ash: 0 wt%

Purity: >99 wt%

Length: 3-30um

SWCNT/DWCNT Mix

SW/DWCNT mix is approx 50/50

Possible MWCNT content <2%

Source Material: CCVD SWCNTs

Primary Functionality: N=H

Other Functionalities: N-H, O=C-N-H2, C≡N

Form Supplied: Dry Powder

Packaging: Nano-suitable airtight container
