COOH Functionalized Single Walled Carbon Nanotubes 98%

$156.25 - $300.00 / per gram

Carboxyl (COOH) functionalized single walled carbon nanotube powder, 98 wt% purity, 1-2 nm outer diameter, length over 100 um. The carboxyl groups improve wetting in water-borne systems and give reactive sites for coupling to epoxy, polyurethane and other polymer matrices. Functional group content is specified on request; the technical data sheet is available below.

Product Price

Description

COOH Functionalized Single Walled Carbon Nanotubes 98%

This is a carboxyl (COOH) functionalized single walled carbon nanotube powder with 98 wt% purity, a 1-2 nm outer diameter and a length over 100 um. The carboxyl groups on the tube surface improve dispersion in water-borne systems and provide sites for covalent coupling to polymer matrices, which makes this grade a fit for epoxy and polyurethane systems and 3D-printing inks.

An OH functionalized version is available as a special order; contact us for lead time.

Specifications

Property Specification
Grade code CTI-COOH
Functional group Carboxyl (COOH)
Functional group content Specification pending, contact us
Outer diameter 1-2 nm
Purity 98 wt%
Length >100 um
Specific surface area (BET) >800 m2/g

Values are typical of production and are not a lot-specific guarantee. Each shipment includes a Certificate of Analysis.

Applications

  • Water-borne dispersions and coatings.
  • Epoxy and polyurethane systems.
  • Covalent coupling to polymer matrices.
  • 3D-printing inks.

Representative data from the TDS for the SWCNT powder series: in polymers, percolation occurs at 0.05-0.2 wt% net SWCNT, with permanent antistatic behavior and no carbon sloughing. Application results depend on formulation, equipment and process conditions; confirm with your own trials.

Dispersion and handling

Disperse by high-shear mixing, bead milling or probe sonication in water (with a dispersant) or resin carriers. Store sealed and dry at room temperature. Use local exhaust and respiratory protection with dry powder. See our dispersion guide and the safety data sheet.

Documentation

Download the technical data sheet (PDF)

Download the SKU 0113 Technical Data Sheet (PDF) for full specifications.

Cited in research: Used by Tai & Lubineau (KAUST) in a heating-rate-triggered 3D conducting SWCNT/PEDOT:PSS transparent conductive film for noncontact moisture sensing. Read the Ultra-Long SWCNT TCF Launch Spotlight. Tai & Lubineau, Scientific Reports 6, 19632 (2016).
